DOT接頭 M68系列
型號 :
DOT-M68
ㆍ工作壓力範圍 / 高達150 psi
ㆍ工作壓力範圍 / -40°F至+200°F
ㆍ牙型 / NPTF
ㆍ工作壓力範圍 / -40°F至+200°F
ㆍ牙型 / NPTF
| 產品型號 | 管材外徑 | NPT牙尺寸 |
| 35-M680401 | 4 mm | 1/16" |
| 35-M680402 | 4 mm | 1/8" |
| 35-M680602 | 6 mm | 1/8" |
| 35-M680604 | 6 mm | 1/4" |
| 35-M680606 | 6 mm | 3/8" |
| 35-M680608 | 6 mm | 1/2" |
| 35-M680802 | 8 mm | 1/8" |
| 35-M680804 | 8 mm | 1/4" |
| 35-M680806 | 8 mm | 3/8" |
| 35-M681004 | 10 mm | 1/4" |
| 35-M681006 | 10 mm | 3/8" |
| 35-M681008 | 10 mm | 1/2" |
| 35-M681204 | 12 mm | 1/4" |
| 35-M681206 | 12 mm | 3/8" |
| 35-M681208 | 12 mm | 1/2" |
| 產品型號 | 管材外徑 | PT牙尺寸 |
| 35-M680602BSPT | 6 mm | 1/8" |
| 35-M680604BSPT | 6 mm | 1/4" |
| 35-M680802BSPT | 8 mm | 1/8" |
| 35-M680804BSPT | 8 mm | 1/4" |
| 35-M680806BSPT | 8 mm | 3/8" |
| 35-M680808BSPT | 8 mm | 1/2" |
| 35-M681004BSPT | 10 mm | 1/4" |
| 35-M681006BSPT | 10 mm | 3/8" |
| 35-M681204BSPT | 12 mm | 1/4" |
| 35-M681206BSPT | 12 mm | 3/8" |
| 35-M681208BSPT | 12 mm | 1/2" |
| 產品型號 | 管材外徑 | 公制牙尺寸 |
| 35-M6806M10 | 6 mm | M10*1.0 |
| 35-M6806M12 | 6 mm | M12*1.5 |
| 35-M6806M14 | 6 mm | M14*1.5 |
| 35-M6806M16 | 6 mm | M16*1.5 |
| 35-M6806M22 | 6 mm | M22*1.5 |
| 35-M6808M10 | 8 mm | M10*1.0 |
| 35-M6808M12 | 8 mm | M12*1.5 |
| 35-M6808M14 | 8 mm | M14*1.5 |
| 35-M6808M16 | 8 mm | M16*1.5 |
| 35-M6808M22 | 8 mm | M22*1.5 |
| 35-M6810M10 | 10 mm | M10*1.0 |
| 35-M6810M12 | 10 mm | M12*1.5 |
| 35-M6810M14 | 10 mm | M14*1.5 |
| 35-M6810M16 | 10 mm | M16*1.5 |
| 35-M6810M22 | 10 mm | M22*1.5 |
| 35-M6812M12 | 12 mm | M12*1.5 |
| 35-M6812M14 | 12 mm | M14*1.5 |
| 35-M6812M16 | 12 mm | M16*1.5 |
| 35-M6812M22 | 12 mm | M22*1.5 |
| 35-M6816M16 | 16 mm | M16*1.5 |
| 35-M6816M22 | 16 mm | M22*1.5 |
ㆍSHPI的D.O.T.接頭符合 D.O.T. FMVSS 571.106標準規範生產
ㆍ剎車系統規格符合SAE J2494標準
ㆍ由C3600/C3700黃銅合金加工而成
ㆍ在所有螺紋上均預塗螺紋密封劑
ㆍ一鍵式快速組裝，減少安裝時間和成本
ㆍ提供各種款式和配置，以滿足車輛應用，使安裝更容易
ㆍ剎車系統規格符合SAE J2494標準
ㆍ由C3600/C3700黃銅合金加工而成
ㆍ在所有螺紋上均預塗螺紋密封劑
ㆍ一鍵式快速組裝，減少安裝時間和成本
ㆍ提供各種款式和配置，以滿足車輛應用，使安裝更容易
ㆍ建議使用管材: SAE J844非金屬剎車制動系統
