省力接頭PT
型號 :
PT-mm
ㆍ工作壓力範圍 / 0~150 psi /0~9.9Kgf/cm2 (0~990 KPa)
ㆍ負壓 /-29.5in Hg/-750 mmHg(-750 Torr)
ㆍ工作溫度範圍 / 32°F~140°F / 0~60°C
ㆍ負壓 /-29.5in Hg/-750 mmHg(-750 Torr)
ㆍ工作溫度範圍 / 32°F~140°F / 0~60°C
| 產品型號 | ØD |
T
(Thread)
|
E | L | A |
H (Hex)
(mm)
|
每袋數量 | 每盒數量 |
| PT 04-01 | 4 | PT 1/8 | 37 | 29.9 | 8 | 10 | 10 | 50 |
| PT 04-02 | 4 | PT 1/4 | 37 | 32 | 10 | 14 | 10 | 50 |
| PT 04-03 | 4 | PT 3/8 | 37 | 33.8 | 11 | 17 | 10 | 50 |
| PT 04-M5 | 4 | M5*P0.8 | 37 | 26.3 | 4 | 10 | 10 | 100 |
| PT 04-M6 | 4 | M6*P1.0 | 37 | 26.8 | 4 | 10 | 10 | 100 |
| PT 06-01 | 6 | PT 1/8 | 38 | 31.5 | 8 | 12 | 10 | 50 |
| PT 06-02 | 6 | PT 1/4 | 38 | 34 | 10 | 14 | 10 | 50 |
| PT 06-03 | 6 | PT 3/8 | 38 | 35.6 | 11 | 17 | 10 | 50 |
| PT 06-04 | 6 | PT 1/2 | 38 | 39.2 | 14 | 21 | 5 | 25 |
| PT 06-M5 | 6 | M5*P0.8 | 38 | 28.4 | 4 | 12 | 10 | 50 |
| PT 06-M6 | 6 | M6*P1.0 | 38 | 28.6 | 4 | 12 | 10 | 50 |
| PT 08-01 | 8 | PT 1/8 | 44.5 | 35 | 8 | 14 | 10 | 50 |
| PT 08-02 | 8 | PT 1/4 | 44.5 | 37 | 10 | 14 | 10 | 50 |
| PT 08-03 | 8 | PT 3/8 | 44.5 | 38.6 | 11 | 17 | 10 | 50 |
| PT 08-04 | 8 | PT 1/2 | 44.5 | 42.9 | 14 | 21 | 5 | 25 |
| PT 10-01 | 10 | PT 1/8 | 56.5 | 42.2 | 8 | 17 | 5 | 25 |
| PT 10-02 | 10 | PT 1/4 | 56.5 | 44.5 | 10 | 17 | 5 | 25 |
| PT 10-03 | 10 | PT 3/8 | 56.5 | 45.5 | 11 | 17 | 5 | 25 |
| PT 10-04 | 10 | PT 1/2 | 56.5 | 48.9 | 14 | 21 | 5 | 20 |
| PT 12-01 | 12 | PT 1/8 | 58 | 44.2 | 8 | 19 | 5 | 25 |
| PT 12-02 | 12 | PT 1/4 | 58 | 46.3 | 10 | 19 | 5 | 25 |
| PT 12-03 | 12 | PT 3/8 | 58 | 48.3 | 11 | 19 | 5 | 25 |
| PT 12-04 | 12 | PT 1/2 | 58 | 50.5 | 14 | 21 | 5 | 20 |
| PT 14-02 | 14 | PT 1/4 | 60.5 | 47.4 | 10 | 19 | 5 | 20 |
| PT 14-03 | 14 | PT 3/8 | 60.5 | 49.6 | 11 | 19 | 5 | 20 |
| PT 14-04 | 14 | PT 1/2 | 60.5 | 52 | 14 | 21 | 5 | 20 |
| PT 16-03 | 16 | PT 3/8 | 61.5 | 55.7 | 11 | 19 | 3 | 12 |
| PT 16-04 | 16 | PT 1/2 | 61.5 | 58.5 | 14 | 21 | 3 | 12 |
ㆍ省力接頭可即時連接管材
ㆍ通過按壓套管，即可輕鬆拔除與管材連接
ㆍ接頭已在螺紋上進行了鐵氟龍處理與O形環
ㆍ黃銅鍍鎳的本體確保抗污染性能，延長產品壽命
ㆍ通過按壓套管，即可輕鬆拔除與管材連接
ㆍ接頭已在螺紋上進行了鐵氟龍處理與O形環
ㆍ黃銅鍍鎳的本體確保抗污染性能，延長產品壽命
ㆍ適用流體類型/空氣
