省力接頭PWT
型號 :
PWT-mm
ㆍ工作壓力範圍 / 0~150 psi /0~9.9Kgf/cm2 (0~990 KPa)
ㆍ負壓 /-29.5in Hg/-750 mmHg(-750 Torr)
ㆍ工作溫度範圍 / 32°F~140°F / 0~60°C
ㆍ負壓 /-29.5in Hg/-750 mmHg(-750 Torr)
ㆍ工作溫度範圍 / 32°F~140°F / 0~60°C
| 產品型號 | ØD |
T
(Thread)
|
E | L | A |
H (Hex)
(mm)
|
每袋數量 | 每盒數量 |
| PWT 04-01 | 4 | PT 1/8 | 22 | 42 | 8 | 10 | 10 | 50 |
| PWT 04-02 | 4 | PT 1/4 | 22 | 45 | 10 | 14 | 10 | 50 |
| PWT 04-03 | 4 | PT 3/8 | 22 | 46 | 11 | 17 | 10 | 50 |
| PWT 04-M5 | 4 | M5*P0.8 | 22 | 39 | 4 | 10 | 10 | 100 |
| PWT 04-M6 | 4 | M6*P1.0 | 22 | 39 | 4 | 10 | 10 | 100 |
| PWT 06-01 | 6 | PT 1/8 | 26 | 45 | 8 | 12 | 10 | 50 |
| PWT 06-02 | 6 | PT 1/4 | 26 | 47 | 10 | 14 | 10 | 50 |
| PWT 06-03 | 6 | PT 3/8 | 26 | 48 | 11 | 17 | 10 | 50 |
| PWT 06-04 | 6 | PT 1/2 | 26 | 51 | 14 | 21 | 5 | 25 |
| PWT 06-M5 | 6 | M5*P0.8 | 26 | 41 | 4 | 12 | 10 | 50 |
| PWT 06-M6 | 6 | M6*P1.0 | 26 | 41 | 4 | 12 | 10 | 50 |
| PWT 08-01 | 8 | PT 1/8 | 30 | 47 | 8 | 14 | 10 | 50 |
| PWT 08-02 | 8 | PT 1/4 | 30 | 49 | 10 | 14 | 10 | 50 |
| PWT 08-03 | 8 | PT 3/8 | 30 | 50 | 11 | 17 | 10 | 50 |
| PWT 08-04 | 8 | PT 1/2 | 30 | 54 | 14 | 21 | 5 | 25 |
| PWT 10-01 | 10 | PT 1/8 | 37 | 57 | 8 | 17 | 5 | 25 |
| PWT 10-02 | 10 | PT 1/4 | 37 | 59 | 10 | 17 | 5 | 25 |
| PWT 10-03 | 10 | PT 3/8 | 37 | 60 | 11 | 17 | 5 | 25 |
| PWT 10-04 | 10 | PT 1/2 | 37 | 63 | 14 | 21 | 5 | 20 |
| PWT 12-01 | 12 | PT 1/8 | 42.5 | 60 | 8 | 19 | 5 | 20 |
| PWT 12-02 | 12 | PT 1/4 | 42.5 | 62 | 10 | 19 | 5 | 20 |
| PWT 12-03 | 12 | PT 3/8 | 42.5 | 63 | 11 | 19 | 5 | 20 |
| PWT 12-04 | 12 | PT 1/2 | 42.5 | 66 | 14 | 21 | 5 | 20 |
| PWT 16-03 | 16 | PT 3/8 | 51.5 | 65.5 | 11 | 19 | 3 | 15 |
| PWT 16-04 | 16 | PT 1/2 | 51.5 | 69 | 14 | 21 | 3 | 15 |
ㆍ省力接頭可即時連接管材
ㆍ通過按壓套管，即可輕鬆拔除與管材連接
ㆍ接頭已在螺紋上進行了鐵氟龍處理與O形環
ㆍ黃銅鍍鎳的本體確保抗污染性能，延長產品壽命
ㆍ通過按壓套管，即可輕鬆拔除與管材連接
ㆍ接頭已在螺紋上進行了鐵氟龍處理與O形環
ㆍ黃銅鍍鎳的本體確保抗污染性能，延長產品壽命
ㆍ適用流體類型/空氣
